Large-Inner Diameter Multi-walled carbon nanotubes （TNLIM）
Product Code：TNLIM

Technical Data of TNLIM (pdf) ( Download )

Product Description:
Timestub^TM   Large-Inner Diameter Multi-walled carbon nanotubes   This kind of products (TNLIM) was prepared by acetylene catalytic decomposition over Ni-based catalyst. The inner diameter is often more than 20nm, and the thickness of the CNTs’wall is about 5nm. Moreover, most of the CNTs have 30-60nm outer diameter.

Property	Unit	Large-Inner Diameter Thin-wall carbon nanotubes	Method of Measurement
		TNLIM
OD	nm	30-60	HRTEM,Raman
ID	nm	20-50	HRTEM,Raman
CNTs Purity	wt%	>60	TGA & TEM
Length	microns	1-10	TEM
SSA	m2/g	>100	BET
ASH	g/cm3	<2.0	HRTEM,TGA
OD=Outer Diameter              ID=Inner Diameter                        SSA=Specific Surface Area
