Flash-Ignition Carbon Nanotubes (TNFIM):
Product Code : TNFIM

TNFIM (Down load)

Product Description:
Timestub^TM ----Flash-ignition carbon nanotubes ---This kind of carbon nanotubes (TNFIM) can be ignited by a household camera flash. It is composed of thin diameter multi-walled carbon nanotubes, amorphous carbon and some Fe nanoparticles. The Fe nanoparticles content is about 25wt% in this product. It is a fresh-made product. It was produced by xylene pyrolysis using ferrocene as catalyst.

Property	Unit	Flash-ignited carbon nanotubes	Method of Measurement
		TNFIM
OD	nm	2-50nm	HRTEM,Raman
CNTs Content	wt%	>50	TGA & TEM
Carbon Cntent	wt%	>70	TGA & TEM
Length	microns	~50	TEM
SSA	m2/g	>300	BET
Fe Content	wt%	<25	TGA & TEM
OD=Outer Diameter              ID=Inner Diameter               SSA=Specific Surface Area
